Single Port Ceramic Beams High Performance High Temperature Resistance

Product Details

Place of Origin: Made In China

Brand Name: Dayoo

Payment & Shipping Terms

Get Best Price
Highlight:

High-Performance Ceramic Beams

,

Single-Port Ceramic Beams

,

High-Temperature Resistance Ceramic Beams

Chemical Resistance:
High
Certifications:
ISO 9001:2015 Certified
Wear Resistance:
High
Temperature Range:
Up To 1500°C
Surface Finish:
Smooth
Application:
High Temperature And Corrosive Environments
Corrosion Resistance:
High
Shape:
Beam
Customization Options:
Available
Number Of Ports:
Single-Port, Multi-Port
Electrical Insulation:
Excellent
Thermal Shock Resistance:
High
Material:
Ceramic
Mechanical Strength:
High
Size:
Various Sizes Available
Chemical Resistance:
High
Certifications:
ISO 9001:2015 Certified
Wear Resistance:
High
Temperature Range:
Up To 1500°C
Surface Finish:
Smooth
Application:
High Temperature And Corrosive Environments
Corrosion Resistance:
High
Shape:
Beam
Customization Options:
Available
Number Of Ports:
Single-Port, Multi-Port
Electrical Insulation:
Excellent
Thermal Shock Resistance:
High
Material:
Ceramic
Mechanical Strength:
High
Size:
Various Sizes Available
Single Port Ceramic Beams High Performance High Temperature Resistance

Single-Port Ceramic Beams With High-Performance And High-Temperature Resistance



The high-strength single-hole ceramic beam is a professional industrial structural component manufactured using advanced ceramic materials, featuring exceptional mechanical properties and high-temperature resistance. Produced from high-purity alumina (Al₂O₃≥95%) or silicon carbide (SiC) through precision forming and high-temperature sintering processes, it incorporates a unique single-hole design that optimizes fluid flow while maintaining structural integrity.

Primary Applications

  • High-temperature industrial kilns: Load-bearing components for tunnel kilns, roller hearth kilns

  • Chemical processing equipment: Structural supports for reaction towers, absorption towers in corrosive environments

  • Semiconductor manufacturing: Load-bearing frames for high-temperature heat treatment equipment

  • Environmental engineering: Corrosion-resistant support structures for flue gas treatment systems

Product Advantages

✓ Ultra-high mechanical strength: Flexural strength ≥300MPa, 30% superior to comparable products
✓ Excellent temperature resistance: Continuous service temperature up to 1600°C (1800°C for SiC type)
✓ Outstanding corrosion resistance: Withstands strong acids, alkalis and other corrosive media
✓ Lightweight design: Density only 1/3 of steel, reducing equipment load
✓ Extended service life: 5-8 times longer lifespan than metal components under equivalent conditions

Technical Specifications

Parameter Alumina Type Silicon Carbide Type
Material Purity Al₂O₃≥95% SiC≥98%
Flexural Strength ≥300MPa ≥450MPa
Maximum Service Temp 1600°C 1800°C
CTE 7.2×10⁻⁶/°C 4.3×10⁻⁶/°C
Single-Hole Diameter 30-100mm (customizable) 30-100mm (customizable)
Standard Length 500-3000mm 500-3000mm

Manufacturing Process

  1. Material selection: High-purity ceramic powders (D50≤1μm)

  2. Precision forming: Isostatic pressing ensures structural uniformity

  3. High-temperature sintering: Controlled atmosphere sintering at 1650°C-2000°C

  4. Precision machining: CNC grinding guarantees dimensional accuracy (±0.2mm)

  5. Rigorous inspection: 100% ultrasonic testing + strength verification

Usage Guidelines

⚠️ Installation requirements: Use dedicated ceramic spacers to avoid direct metal contact
⚠️ Temperature control: Recommended heating rate ≤3°C/min
⚠️ Load limitations: Never exceed rated load capacity
⚠️ Maintenance: Regular surface inspection and carbon deposit removal

After-Sales Service

  • Technical support: Free installation guidance and usage training

  • Customization service: Accepts non-standard dimensions and special performance requirements

  • Emergency response: Technical support within 48 hours

FAQ

Q: What is the maximum load capacity?
A: Standard products support 300kg/m, with special models reaching 500kg/m.

Q: Precautions for use in reducing atmospheres?
A: Recommend silicon carbide material or special surface treatment for alumina products.

Q: How to handle beam fracture?
A: Immediately cease use and contact technical support for failure analysis.
