High Purity Silicon Carbide Ceramic Nozzles for Industrial Applications

Product Details

Place of Origin: Made In China

Brand Name: Dayoo

Payment & Shipping Terms

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                si3n4 carbide ceramic, carbide ceramic high purity, si3n4 ceramic silicon


Mineral Type:	Silicon Carbide	Drawing Format:	2D/(PDF/CAD)3D(IGES/STEP)
Quality Control:	100% Inspection	Product:	Silicon Carbide Head
Max Operating Temperature:	1400°C	Wear Resistance:	Excellent
Density:	3.21 G/cm3	Surface Treatment:	Natural Or Polishing
Compressive Strength:	2000 MPa	Advantage:	High Temp Resistant
Volume Resistivity:	5*10^6Ω.cm	Dielectric Strength:	35 KV/mm
Tensile Strength:	200 MPa	Indicated Porosity:	＜0.2%
Content:	99% SIC

Mineral Type:	Silicon Carbide
Drawing Format:	2D/(PDF/CAD)3D(IGES/STEP)
Quality Control:	100% Inspection
Product:	Silicon Carbide Head
Max Operating Temperature:	1400°C
Wear Resistance:	Excellent
Density:	3.21 G/cm3
Surface Treatment:	Natural Or Polishing
Compressive Strength:	2000 MPa
Advantage:	High Temp Resistant
Volume Resistivity:	5*10^6Ω.cm
Dielectric Strength:	35 KV/mm
Tensile Strength:	200 MPa
Indicated Porosity:	＜0.2%
Content:	99% SIC

High Purity Silicon Carbide Ceramic Nozzles for Industrial Applications

Silicon Carbide Ceramics Si₃N₄ High Purity

Product Specifications

Attribute	Value
Color	Black
Advantage	High Precision
Compressive Strength	2,000 MPa
Hardness	9.5 Mohs
Mineral Type	Silicon Carbide
Product	Silicon Carbide Rings
Feature	High Temperature Resistance
Thermal Conductivity	120 W/mK
Wear Resistance	Excellent
Thermal Expansion	4.3 X 10-6/K
Type	Nozzles
Material	Silicon Carbide
Flexural Strength	400 MPa
Product Form	Seal rings
Application	Industrial ceramic

Product Description

As an outstanding representative of advanced ceramic materials, silicon carbide precision ceramics redefine material application standards across multiple high-tech fields with their unique properties:

Ultra-high purity (99.99%) for semiconductor applications
Exceptional plasma corrosion resistance
High temperature resistance (continuous service up to 1600°C)
Excellent wear resistance and dimensional stability
Superior thermal shock resistance

Our silicon carbide ceramic components are ideal for demanding applications in:

Semiconductor manufacturing: Etching and deposition processes
Industrial applications: High-wear environments and thermal management
Aerospace: Thermal protection systems for spacecraft

We provide comprehensive customization services from powder preparation to finished product processing, including specialized techniques like precision molding and ultra-precision polishing to meet your most demanding material performance requirements.

High Purity Silicon Carbide Ceramic Nozzles for Industrial Applications 0
