Silicon Carbide Ceramics The Superior Material For High-Temperature Performance With Free Silicon Content

Product Details

Place of Origin: Made In China

Brand Name: Dayoo

Payment & Shipping Terms

Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram

Get Best Price

Product Details

Product Description

Highlight:

Material:	Silicon Carbide	Free Silicon Content:	≤10%
Sic Content:	≥98%	Color:	Black
Bending Strength:	400 MPa	Micron:	150
Application:	Sintering Parts	Flexural Strength:	400 MPa
Compressive Strength:	2000 MPa	Dielectric Constant:	9.7

Material:	Silicon Carbide
Free Silicon Content:	≤10%
Sic Content:	≥98%
Color:	Black
Bending Strength:	400 MPa
Micron:	150
Application:	Sintering Parts
Flexural Strength:	400 MPa
Compressive Strength:	2000 MPa
Dielectric Constant:	9.7

Silicon Carbide Ceramics The Superior Material For High-Temperature Performance With Free Silicon Content

Silicon Carbide Ceramics: The Ultimate Material for High-Temperature Performance

Product Specifications

Attribute	Value
Free Silicon Content	≤10%
Sic Content	≥98%
Thermal Shock Resistance	Good
Color	Black
Bending Strength	400 MPa
Drawing Format	2D/(PDF/CAD)3D(IGES/STEP)
Micron	150
Application	sintering parts
Flexural Strength	400 MPa
Compressive Strength	2000 MPa
Dielectric Constant	9.7
Mechanical Strength	High
Maximum Operating Temperature	1650°C
Material	Silicon Carbide
Hardness	9.5 Mohs
Temperature	1600℃
Advantage	corrosion resistance
Thermal Expansion Coefficient	4.0 x 10-6/°C
Thermal Conductivity	120 W/mK
Chemical Resistance	High
Surface Finish	Smooth
Modulus Of Elasticity	300-330 Gpa
Chemical Inertness	High
Content	99% SIC
Volume Resistivity	5*10^6Ω.cm
Electrical Resistivity	10^-3 ohm-cm
Feature	High Temperature Resistance
Corrosion Resistance	High
Primary Application	Paint Prep, Coating & Corrosion Removal
Electrical Conductivity	Semi-conductive
Product Colour	Black
Abrasion Resistance	Excellent
Indicated Porosity	＜0.2%
Usage	Industry Usage
Thermal Expansion	4.5 X 10-6/K

Product Description

Silicon Carbide Ceramics represent a high-performance inorganic material valued for its exceptional thermal stability, mechanical strength, and excellent chemical resistance. This material serves critical roles in high-temperature and demanding industrial applications where reliability and durability are paramount.

Key Characteristics

High Thermal Conductivity - 120 W/mK for efficient heat dissipation in demanding environments
Exceptional Thermal Shock Resistance - Maintains structural integrity under rapid temperature changes
Superior Mechanical Strength - 400 MPa bending strength and 2000 MPa compressive strength
Excellent Chemical Resistance - Withstands corrosive environments and maintains performance
High Temperature Capability - Operates reliably up to 1650°C
Outstanding Abrasion Resistance - 9.5 Mohs hardness for long service life in wear applications

Manufacturing Process

Raw Material Preparation - High-purity silicon carbide powder with ≥98% SiC content
Forming - Precision shaping through pressing or casting methods
Sintering - High-temperature firing at approximately 1600℃ to achieve final density
Finishing - Precision machining and surface treatment to meet exact specifications

Applications

High-temperature furnace components
Semiconductor manufacturing equipment
Mechanical seals and bearings
Wear-resistant components
Thermal management systems
Corrosion-resistant industrial parts
Advanced ceramic coatings
Specialized sintering applications
